Tekla Steel Detailing & Structural Drawings
Vector Plans specializes in Tekla Structures–based steel detailing — from 3D BIM models and GA drawings through fabrication-ready shop drawings, single part drawings, and complete erection packages delivered to fabricators and contractors worldwide.
What We Deliver
Full-scope Tekla steel detailing — model to drawing set.
General Arrangement and Construction Drawings produced directly from the Tekla 3D model — accurate, fully dimensioned, and ready for site use or permit submission.
CNC-ready shop drawings extracted from Tekla models — full connection details, weld symbols, bolt schedules, and material callouts to drive fabrication with zero ambiguity.
Individual part drawings for every member and plate, plus fully sequenced erection drawings that guide the steel-fix team from first column to final bolt-up.
Every drawing we produce comes directly from the Tekla Structures 3D model — guaranteeing that shop drawings, erection drawings, and single part drawings are fully coordinated, clash-free, and consistent across the entire package. No disconnected 2D work. No coordination errors.
How It Works
Share your structural drawings, IFC/STEP files, or sketches. We confirm scope, steel standard, drawing format, and delivery schedule before any modeling begins.
Our detailers build the full Tekla Structures model — profiling every member, designing connections, and applying your fabricator's standard templates and libraries.
We issue drawings for your review. Markups and revision requests are turned around quickly — all changes flow back through the model for guaranteed consistency.
Receive the final drawing package — PDF, DWG, and Tekla model files — along with BOMs and NC data, ready for fabrication shop floor use.
Why Vector Plans
We combine deep Tekla Structures expertise with a thorough understanding of international fabrication codes and real-world steel construction workflows — keeping your fabrication floor productive and your projects on schedule.
Projects Delivered
600+
Commercial, industrial, PEMB, and heavy infrastructure steel projects delivered to fabricators worldwide.
Drawing Accuracy
98%
First-issue accuracy rate — fewer RFIs, fewer revision cycles, and faster fabrication start dates for our clients.
Get In Touch
Ready to get started? Share your structural drawings or model files and we'll respond promptly with a scope review, timeline, and quote for your Tekla detailing package.
